With UDE® Universal Debug Engine PLS offers on top solutions for software development of systems-on-silicon including debug support for the 16-/32- and 64-bit microcontrollers XC166, XC2000, XE166, XMC4500, STM32, C166S V2, SDA6000, TriCore™ and AURIX™ TC25, TC27, TC29, TC33, TC35, TC36, TC37, TC38, TC39 from Infineon and STMicroelectronics, Power Architecture® MPC56, MPC57, MPC58, S32, S32V234 from NXP™, S32R from NXP™, PowerPC™ PPC440SPe from AMCC, Cortex®-R52 Stellar from STMicroelectronics, Power Architecture® SPC56, SPC57, SPC58 from STMicroelectronics, Arm7™, Arm9™, Arm11™, Cortex, Cortex-M0, Cortex-M0+, Cortex-M3, Cortex-M33, Cortex-M4, Cortex-M7, Cortex-R4, Cortex-R52, Cortex-A8, Cortex-A9, RH850, RISC-V, ARC, SuperH™ SH-2A, STM32, S32V, S32K, XScale™ derivatives in a new multi-core debug environment as well as technical support.

Latest Enhancements of UDE®

The extensive feature list includes functions like: high speed and flexible target access via JTAG, cJTAG with OCDS L1, EmbeddedICE, OnCE, COP, DAP, DAP2, SWD support, OCDS L2 trace, MCDS trace, miniMCDS trace, CoreSight™ trace, ETM trace, ETB trace, Nexus trace, ASC, SSC, 3Pin and CAN, in-system FLASH memory programming of FLASH / OTP with UDE® Memtool, support of various RTOS, OSEK® and test automation tools. UDE® latest version offers new features:

Complete Eclipse based TriCore Development Platform

• Complete Eclipse based TriCore / TriCore AURIX TC4, TC39, TC37, TC29, TC27 MCA (Multi-core Architecture) Development Platform and emulation kits with DAP/DAP2 support

• DXCPL support

• AURIX TC4, TC3 FLASH Programming: Support for 'Software Over The Air' (SOTA) mode

• Hardware Security Modul (HSM), Generic Timer Modul (GTM), CIF video stream trace supported.

Complete Eclipse based Power Architecture Development Platform

• Complete Eclipse based Development Platform

• Improved Power Architecture® MPC5746M (incl. Emulation Device), MPC5744K, MPC5777M, MPC5744P, S32R, SPC57EM80, SPC58EG84 support

• Hardware Security Modul (HSM), Generic Timer Modul (GTM)

• Universal Emulation Configurator (UEC) and Nexus Trace support Sequence Processing Unit (SPU)

• Time Processor Unit Multi-eTPU, Dualcore and LockStep supported

• Support JTAG over MCAN debugging added

• VLE technology support, Nexus trace support.

Enhanced Arm7, Arm9, Arm11, Cortex, Cortex-M0, Cortex-M0+, Cortex-M3, Cortex-M4, Cortex-M7, Cortex-R4, Cortex-R52, Cortex-A8, Cortex-A9, Cortex-A53, RH850, RISC-V, ARC support

• Multi-core Debug via one JTAG chain support, and CoreSight GigaByte Trace

• Cortex-A9, Cortex-A53, Cortex-M0, Cortex-M3, Cortex-M4, Cortex-R4, Cortex-R52 Xilinx Zynq-700, LPC1850, LPC4300, XMC1000, XMC4000, K60 Kinetis, FM3, TMS570, STM32, S32V, S32K, S32V234, Stellar support

• RH850 support

• RISC-V support

• Synopsys ARC support

• SPIFI Programming support

• Arm / Cortex Thumb/Thumb2 mode code supported.

Further features and enhancements

• AURORA Gigabit Trace (AGBT) with UAD3+ for AURIX, MPC57, MPC58, S32R and SPC57, SPC58 Emulation Devices

• SERIAL Gigabit Trace (SGBT) with UAD3+ for AURIX TC4x

• AURORA Trace for Cortex-R52 Stellar Automotive Devices

• XCP Support for Cortex-R52 Stellar and S32Z Automotive Devices

• Synopsys ARC support for ARC EM, EV and ARC HS

• Universal Trace Framework (UTF) with persistent trace streams for offline analysis of captured and saved trace data

• Unique search function supports the rapid analysis of very large amounts of trace data, bookmarks of trace points introduced

• Call Graph analysis for efficient investigation of runtime behavior

• Displaying of ECU variables for measurement and calibration purposes based on A2L files according to ASAM MCD-2 MC description standard

• Improved trace features as persistent storage of trace sessions for analysis, comprehensive filters

• Core- or user-specific visibility groups

• Test automation with Python scripts and other scripting laguages

• Execution Sequence Chart for visualization the program flow and its sequence in time

• Function Sequence Chart improved

• Graphical code coverage analysis allows branch coverage to fulfil ISO26262 requirements

• Automatic generation of Code Coverage reports for further analysis

• Profiling functions based on code trace data from On-chip Emulators (MCDS, miniMCDS and SPU) including Aurora, Nexus, ETM, ETB, ITM, PTM, FTM trace and also IP snooping or simulator output

• Accumulation of Profiling and Coverage data over multiple trace measurement tasks

• Data trace for GTM Multi-channel sequencers

• GTM trace support for miniMCDS

• Synopsys ARC SmaRT trace support

• PikeTec‘s Time Partition Testing (TPT) systematic test case design supported

• Tool Qualification Packages (TQPs) for the TESSY test platform for various architectures and cross compilers coupled with the full range of UDE® features

• Extended multi-core-run control manager, extended multicore/ multi-program loader

• RTOS-Awareness for RTX (CMSIS)

• Improved Graphical window with Hardware Trace (MCDS, miniMCDS, NEXUS, and ETM) Signal Chart, Graphical display of IP and function traces

• Supported OS: Windows® 10 (64-bit), Windows® 11 (64-bit).
